Ideal for custom battery packs requiring high performance, durability, and safety.
Voltage: 3.67V
Capacity: 30Ah
Internal Resistance: 1.46mΩ (full-tab design)
Max Discharge Current: 120A
Dimensions: 46 × 96.5 mm
Weight: 415g (≈0.91 lbs)
Cycle Life: 1,000+ charge/discharge cycles
Robust Performance:
High-capacity 30Ah output with 120A peak discharge.
Low internal resistance (1.46mΩ) for efficient power delivery.
Extended Lifespan:
1,000+ cycles ensure long-term reliability and cost-effectiveness.
Safety Certified:
Compliant with CE, RoHS, UN38.3, and other international standards.
Custom Assembly Support:
Flexible options for PCB, wiring, and connectors.
Warranty Protection:
Backed by a 1-year warranty for added confidence.
| Item |
Specifications |
|
Normal Capacity |
30.0 Ah; 1/3C; 25±2°C, 2.8~4.2 V |
|
Normal Energy |
110.0Wh; 1/3C, 25±2°C, 2.8~4.2 V |
|
Nominal Voltage |
3.67V (1/3C) |
|
Discharge Capacity |
≥30.0 Ah; 25°C, 1/3C, 2.8~4.2 V; |
|
Discharge Energy |
≥110.0 Wh25°C, 1/3C, 2.8~4.2V |
|
AC Internal Resistance of BOL Status |
≤1.8 mΩ |
|
DC Internal Resistance of BOL Status |
≤4.0 mΩ |
|
Standard Charge Current |
10Ah (1/3C) |
|
Standard Discharge Current |
10Ah (1/3C) |
|
Maximum Continuous Charging Current |
1C; (0%, 90%) SOC |
|
Cycle Life |
1000 cycle, 25°C, 3.0~4.15 V, 0.5C/0.5C |
|
Environmental Temp |
0~45°C; Charge Temp |
|
-20~45°C; Discharge Temp |
|
|
Storage Temp |
0~25°C; 1 Year |
|
0~45°C; 3 Month |
|
|
-20~55°C; 1 Month |
|
|
Self Discharge Rate@25¡æ |
First month 0.05 V/ month Followed by 0.03V/ month |
|
Shipping Voltage Range |
3.5~3.8V |
|
Multiple Rate Discharge |
25°C, 3C; ≥90% Of 1C Discharge Capacity |
|
High and Low Temperature Discharge |
-20°C, 1C; Capacity Retention Rate ≥80 % |
|
55°C, 1C; Capacity Retention Rate ≥90 % |
|
|
Cell Weight (With Insulating Film) |
415±10 g |
|
Cell Dimension |
£¨46.16±0.15)×(96.50±0.35)mm |
Perfect for energy storage systems, AGVs, electric scooters, e-bikes, two-wheelers, and electric sightseeing vehicles.
