48V 5.76Kwh LTO Battery Residential Home Energy Storage System

Home Battery Energy Storage System Solution

48V 100ah 5.76Kwh LTO Battery Residential Home Energy Storage System to resolve the power supply issue for all equipment in the house

Individual pricing for large scale projects and wholesale demands is available.

Mobile/WhatsApp/Wechat: +86 156 0637 1958
Email: info@evlithium.com

Description

Features

High Safety: 240℃ without thermal runaway
Long Cycle Life: Cycle life more than 20 years
High Rate: 6-minute charging and discharging
Wide Working Temperature: -40℃ to 60℃
Recycle: Recycle >97%
3+ Cycles a day

Specifications

Items	Specifications
Rated Capacity(KWh)	5.76
Combination Mode	3P20S
Rated Voltage(V)	48
Operating Voltage Range(V)	42~58
Rated Charge and Discharge Current(A)	100
Rated Charge and Discharge Power(KW)	5
Operating Temperature Range(℃)	‑40~60
Relative Humidity(%)	0‑95%
Max.Working Altitude(m)	4,000
Cycle Life (cycles)	25,000
Communication Mode	RS485/CAN
Installation Mode	Stack Vertically
Weight(Kg)	91(About)
Size	(620×650×225)±3 mm

Deatails

Dimensions

display

The hybrid inverter solution rapidly responds to EMS dispatching commands and builds an intelligent, user‑friendly power supply system together with rooftop photovoltaics for higher power‑utilization efficiency. It supports seamless switching with the utility grid to deliver a more stable power supply.

Product circuit diagram display

Applications

applications
